Besa UI Automation Getting Started

A light-weight and fast UI Automation Server component. Simple usage. Only Drag and Drop and Set Active property to True. It is ready. Supports custom component definition.



This is the documentation of the the settings of the TbsUIVCLServer component. We will then give some examples of custom component definitions. For more information about Microsoft UI Automation: UI Automation Overview

You can use Katalon Studio with WinAppDriver.

Delphi has two type visual control type:

  1. Windows controls (TWinControl based like: TButton,TPanel...)
  2. Native Delphi controls (TGraphicControl based like: TLabel,TSpeedButton...)

If you want to add your custom component to Besa UI Automation system. You must create a proxy class. If your class is TWinControl based your proxy class must be derivated from TbsWinControl else must be derivated from TbsControl. This proxy class must be registered with AddVCLProviderClass method.

Sample code for TEdit control:

uses
  bsUICommon, bsUIVCL, BSUIAutomationCore, ...;

type
  // For windows controls used TbsWinControl
  TbsUiEdit=class(TbsWinControl)
  public
    function DoGetValue:String; override;
    function DoSetValue(AValue:String):Boolean; override;
    function DoGetControlType:Integer; override;
  end;

implementation

{ TbsUiEdit }

function TbsUiEdit.DoGetControlType: Integer;
begin
  Result:= UIA_TextControlTypeId;
end;

function TbsUiEdit.DoGetValue: String;
begin
  Result := TCustomEdit(FControl).Text;
end;

function TbsUiEdit.DoSetValue(AValue: String):boolean;
begin
  Result:=True;
  TCustomEdit(FControl).Text:=AValue;
end;

initialization
  //Register your provider class
  AddVCLProviderClass(TCustomEdit, TbsUiEdit);
end.

Sample code for TLabel control:

uses
  bsUICommon, bsUIVCL, BSUIAutomationCore, ...;

type
  // For delphi controls used TbsControl
  TbsUiLabel=class(TbsControl)
    function DoGetValue:String; override;
    function DoGetControlType:Integer; override;
  end;

implementation

{ TbsUiLabel }

function TbsUiLabel.DoGetControlType: Integer;
begin
  Result:=UIA_TextControlTypeId;
end;

function TbsUiLabel.DoGetValue: String;
begin
  Result:=TLabel(FControl).Caption;
end;

initialization
  AddVCLProviderClass(TCustomLabel, TbsUiLabel);
end.

Besa UI Automation components support Grids. If you have a grid component (must be TWinControl based) you must create a proxy class from TbsTable class. A table has Rows and Cells. And you must create proxy class for rows and cells. Proxy class required for rows and cells because UI Automation need bounds rectangle and set/get value for cells. Your row class must be derivated from TbsTableRow and cell class derivated from TbsTableCell.

if your component based:

Delphi Class UI Class
TCustomGrid TbsUiCustomGrid
TStringGrid TbsUiStringGrid
TDBGrid TbsUiCustomDBGrid
else TbsTable

Sample code for TStringGrid's base class TCustomGrid control:

uses
  bsUICommon, bsUIVCL, BSUIAutomationCore, ...;

type
  TbsUiCustomGridCell=class(TbsTableCell)
  protected
    function DoSetValue(AValue:String):Boolean; override;
    function DoGetValue:String; override;
    function GetCellRect(ARow,AColumn:LongWord): TRect; override;
  end;

  TbsUiCustomGridRow=class(TbsTableRow)
  public
    function GetTableCellClass:TbsTableCellClass; override;
    function GetRowRect(ARow:LongWord): TRect; override;
  end;

  TbsUiCustomGrid=class(TbsTable)
  protected
    function DoGetRowCount:Cardinal; override;
    function DoGetColumnCount:Cardinal; override;
    function DoGetColumnHeaders: TArrayOfString; override;
    function GetTableRowClass:TbsTableRowClass; override;
  end;

implementation

{ TbsUiCustomGrid }

function TbsUiCustomGrid.DoGetColumnCount: Cardinal;
begin
  Result:=// Get Col Count;
end;

function TbsUiCustomGrid.DoGetRowCount: Cardinal;
begin
  Result:= // Get Row Count;
end;

function TbsUiCustomGrid.DoGetColumnHeaders: TArrayOfString; override;
begin
  Result:=// Return Column Headers as array of string
end;

function TbsUiCustomGrid.GetTableRowClass: TbsTableRowClass;
begin
  Result:= TbsUiCustomGridRow;
end;

{ TbsUiCustomGridRow }

function TbsUiCustomGridRow.GetRowRect(ARow: LongWord): TRect;
begin
  // Calculate Row Rect.
  Result:=CalculatedRect;
end;

function TbsUiCustomGridRow.GetTableCellClass: TbsTableCellClass;
begin
  Result:= TbsUiCustomGridCell;
end;

{ TbsUiCustomGridCell }

function DoSetValue(AValue:String):Boolean; override;
begin
   //Set Row,Col cell's value
   Result:=True; // if succesfully
end;

function DoGetValue:String; override;
begin
  Result:=//Get Row, Col cell's value
end;

function TbsUiCustomGridCell.GetCellRect(ARow, AColumn: LongWord): TRect;
begin
  // Calculate Cell Rect
  Result:=CalculatedRect;
end;

initialization
  AddVCLProviderClass(TCustomGrid, TbsUiCustomGrid);

end.
